SUD40N06-25L N-Channel MOSFET

SUD40N06-25L N-Channel 60 V (D-S) 175 °C MOSFET PRODUCT SUMMARY VDS (V) 60 rDS(on) (W) 0.022 @ VGS = 10 V 0.025 @ VGS = 4.5 V ID (A)a 30 30 D TO-252 G Drain Connected to Tab G D S S Order Number: SUD40N06-25L N-Channel MOSFET Top View ABSOLUTE MAXIMUM RATINGS (TC = 25_C UNLESS OTHERWISE NOTED) Parameter Gate-Source Voltage Continuous Drain Current (TJ = 175_C)b Pulsed Drain Current Continuous Source Current (Diode Conduction) Avalanche Current Repetitive Avalanche Energy (Duty Cycle v 1%.

SUD40N06-25L Datasheet (351.29 KB)
