GBJ408, GBJ4005 - Single Phase 4.0 AMPS. Glass Passivated Bridge Rectifiers

Datasheet Details

Part number: GBJ408, GBJ4005
Manufacturer: GOOD ELECTRONIC
File Size: 303.50 KB
Datasheet: GBJ4005-GOODELECTRONIC.pdf
Description: Single Phase 4.0 AMPS. Glass Passivated Bridge Rectifiers
Note: This datasheet PDF includes multiple part numbers: GBJ408, GBJ4005.
Please refer to the document for exact specifications by model.

0.995(25.3) 0.983(24.7) 0.134(3.4) 0.122(3.1) 0.157(4.0) 0.150(3.8) 0.126(3.2) 0.203(5.16) 0.181(4.60) 0.602(15.3) 0.579(14.7) 0.382(9.7) 0.365(9.3).
UL Recognized File#230084.
Ideal for printed circuit board.
Surge overload rating-50amperes peak.
Plastic material has underwriters laboratory flammability classification 94V-0.
Mounting position:Any 0.146(3.7 0.11)8(3.0 0.153(3.9) 0.134(3.4) 0.701(17.8) 0.669(17.0) 0.083(2.1) 0.069(1.7) 0.057(1.45) 0.041(1.05) 0.04.
