GS81302S36GE Datasheet - GSI Technology

GS81302S36GE 144Mb SigmaSIO DDR -II Burst of 2 SRAM

Table Symbol Description Type Comments SA Synchronous Address Inputs Input * R/W Read/Write Contol Pin Input Write Active Low; Read Active High NW0 *NW1 Synchronous Nybble Writes Input Active Low x08 Version BW0 *BW1 Synchronous Byte Writes Input Active Low x18.

GS81302S36GE Features

* Simultaneous Read and Write SigmaSIO™ Interface

* JEDEC-standard pinout and package

* Dual Double Data Rate interface

* Byte Write controls sampled at data-in time

* DLL circuitry for wide output data valid window and future frequency scaling

* Burst

GS81302S36GE Datasheet (496.83 KB)

Preview of GS81302S36GE PDF
GS81302S36GE Datasheet Preview Page 2 GS81302S36GE Datasheet Preview Page 3

Datasheet Details

Part number:

GS81302S36GE

Manufacturer:

GSI Technology

File Size:

496.83 KB

Description:

144mb sigmasio ddr -ii burst of 2 sram.
