S70K - Silicon Standard Recovery Diode

Product Overview

GeneSic

Part number	S70K
Manufacturer	GeneSic
File Size	625.31 KB
Description	Silicon Standard Recovery Diode
Datasheet	S70K Datasheet
Additional preview pages of the S70K datasheet.

High Surge Capability.
Types up to 1600 V VRRM DO-5 Package VRRM = 100 V - 1600 V IF = 70 A Note: 1. Standard polarity: Stud is cathode. 2. Reverse polarity (R): Stud is anode. 3. Stud is base. Maximum ratings, at Tj = 25 °C, unless otherwise specified Parameter Repetitive peak reverse voltage RMS reverse voltage DC blocking voltage Continuous forward current Surge non-repetitive forward current, Half Sine Wave Operating temperature Storage temperature Symbol VRRM VRMS VDC.
