G2985, G2985-GlobalMixed - DDR Termination Regulator

G2985 Description

Global Mixed-mode Technology DDR Termination Regulator G2985 .

G2985 Features

* VIN Input Voltage Range: 2.5V to 5.5V
* VLDOIN Voltage Range: 1.1V to 3.5V
* Support DDR I (1.25 VTT), DDR II (0.9 VTT), DDR III (0.75 VTT), DDR IIIL (0.675VTT) and DDR IV (0.6 VTT) Requirements
* Stable with Output Ceramic Capacitor
* PGOOD to Monitor Outpu

G2985 Applications

* DDR I/II/III/IIIL/IV Memory Termination
* SSTL_3, SSTL_2, SSTL_18, SSTL_15
* HSTL Termination
* Notebook/Desktop/Server
* Telecom/Datacom, GSM Base Station, LCD-TV/PDP-TV, Copier/Printer, Set-Top Box Ordering Information ORDER NUMBER G2985RE1D Note: RE: TDF

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: G2985, G2985-GlobalMixed. Please refer to the document for exact specifications by model.

Datasheet Details

Part number
G2985, G2985-GlobalMixed
Manufacturer
Global Mixed-mode Technology
File Size
62.88 KB
Datasheet
G2985-GlobalMixed-modeTechnology.pdf
Description
DDR Termination Regulator
Note
This datasheet PDF includes multiple part numbers: G2985, G2985-GlobalMixed.
Please refer to the document for exact specifications by model.
