HCD300 Datasheet, Ocxo, Golledge Electronics

HCD300 Features

• Ocxo  Temperature stability down to 50ppb  Single 5V oven & oscillator supply  Low profile compact package  Standard European IEC CO-08 pin-out  Custom options available Standard Model

PDF File Details

Part number:

HCD300

Manufacturer:

Golledge Electronics

File Size:

123.38kb

Download:

📄 Datasheet

Description:

Ocxo.

TAGS

HCD300

Golledge Electronics
