HSD140PHW1-A02 - TFT LCD Panel

Product Overview

HannStar

Datasheet Details

Part number	HSD140PHW1-A02
Manufacturer	HannStar
File Size	733.74 KB
Description	TFT LCD Panel
Datasheet	HSD140PHW1-A02 Datasheet
Additional preview pages of the HSD140PHW1-A02 datasheet.

Product details

Description

of change A02 Formal Product Information was first issued.2/26 1.0 The information contained in this document is the exclusive property of HannStar Display Corporation.It shall not be disclosed, distributed or reproduced in whole or in part without written permission of HannStar Display Corporation.One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com Global LCD Panel Exchange Center www.panelook.com Document Title Document No.H

Features

Ŷ 14 (16:9 diagonal) inch configuration Ŷ One channel LVDS interface Ŷ 262K color by 6 bit R. G. B signal input Ŷ RoHS Compliance Ŷ Halogen Free 1.3 General information Item Outline Dimension Display area Number of Pixel Pixel pitch Pixel arrangement Display mode NTSC Surface treatment Weight Back-light Power Logic System Consumption B/L System Specification 323.5(Typ) x 192(Typ) x 5.2 (Max) 309.40(H) x 173.95(V) 1366 RGB (H) x 768(V) 0.2265(H) x 0.2265(V) RGB Vertical stripe Norma.
