HSD140PHW1-B - Color TFT-LCD Module

Product Overview

HannStar

Datasheet Details

Part number	HSD140PHW1-B
Manufacturer	HannStar
File Size	487.17 KB
Description	Color TFT-LCD Module
Datasheet	HSD140PHW1-B Datasheet
Additional preview pages of the HSD140PHW1-B datasheet.

Product details

Description

of change 1.0 30 Oct, 2008 B00 Preliminary Product Specification was first issued.The information contained in this document is the exclusive property of HannStar Display Corporation.It shall not be disclosed, distributed or reproduced in whole or in part without written permission of HannStar Display Corporation.HannStar Display Corp.Document Title HSD140PHW1-B Preliminary Specification Page No.3/26 Document No.Revision 1.0 Contents 1.0 General description ………………………………… p.4

Features

14 (16:9 diagonal) inch configuration.
One channel LVDS interface.
262K color by 6 bit R. G. B signal input.
RoHS Compliance.
Halogen Free 1.3 General information Item Outline Dimension Display area Number of Pixel Pixel pitch Pixel arrangement Display mode NTSC Surface treatment Weight Back-light Power Logic System Consumption B/L System Specification 323.5 x 192 x 4.9 (Typ. ) 309.40(H) x 173.95(V) 1366 RGB (H) x 768(V) 0.2265(H) x 0.2265(V) RGB Vertical s.
