HDSP3730 Datasheet, Displays, Hewlett-Packard

HDSP3730 Features

• Displays
• High Light Output Typical Intensities of Up to 7.0 mcd/seg at 100 mA pk 1 of 5 Duty Factor
• Capable of High Current Drive Excellent for Long Digit String Multiplexing

PDF File Details

Part number:

HDSP3730

Manufacturer:

Hewlett-Packard

File Size:

299.85kb

Download:

📄 Datasheet

Description:

(hdsp-xxxx) 7-segment displays. The HDSP-3530/-3730/-5530/ -3900 and HDSP-4030/-4130/ -5730/-4200 are 7.6 mm, 10.9 mm/14.2 mm/20.3 mm high efficiency red and yellow

HDSP3730 Application

• Applications such as Automotive and Avionic Instrumentation, Point of Sale Terminals, and Gas Pump. Devices Part No. HDSP3530 3531 3533 3536 4030 4
