HM5116400 - (HM5116400 / HM5117400) 4M DRAM

This page provides the datasheet information for the HM5116400, a member of the HM5117400 (HM5116400 / HM5117400) 4M DRAM family.

Datasheet Summary

Description

The Hitachi HM5116400 Series, HM5117400 Series are CMOS dynamic RAMs organized 4,194,304-word × 4-bit.

They employ the most advanced 0.5 µm CMOS technology for high performance and low power.

The HM5116400 Series, HM5117400 Series offer Fast Page Mode as a high speed access mode.

Features

  • Single 5 V (±10%) Access time: 50 ns/60 ns/70 ns (max) Power dissipation  Active mode : 495 mW/440 mW/385 mW (max) (HM5116400 Series) : 550 mW/495 mW/440 mW (max) (HM5117400 Series)  Standby mode : 11 mW (max) : 0.83 mW (max) (L-version) Fast page mode capability Long refresh period  4096 refresh cycles : 64 ms (HM5116400 Series) : 128 ms (L-version)  2048 refresh cycles : 32 ms (HM5117400 Series) : 128 ms (L-version) 3 variations of refresh  RAS -only refresh.

📥 Download Datasheet

Datasheet preview – HM5116400

Datasheet Details

Part number HM5116400
Manufacturer Hitachi
File Size 766.62 KB
Description (HM5116400 / HM5117400) 4M DRAM
Datasheet download datasheet HM5116400 Datasheet
Additional preview pages of the HM5116400 datasheet.

📁 Similar Datasheet

  • HM5116100 - 16M FP DRAM (Hitachi Semiconductor)
  • HM5117400AS7GS - CMOS 4M DRAM (ETC)
  • HM5117800BJ - CMOS 2M x 8-Bit DRAM (ETC)
  • HM5117805 - 16 M EDO DRAM (2-Mword X 8-bit) 2 k Refresh (Elpida Memory)
  • HM51 - HM50 / HM51 Series / Miniature Power Inductors (BI Technologies)
  • HM51-xxx - HM50 / HM51 Series / Miniature Power Inductors (BI Technologies)
  • HM514170C - Dynamic Random Access Memory (Hitachi Semiconductor)
  • HM514170D - (HM514170D / HM514270D) Dynamic RAM (Hitachi Semiconductor)
  • HM514260A - 16-Bit Dynamic Random Access Memory (Hitachi Semiconductor)
  • HM514260AL - 16-Bit Dynamic Random Access Memory (Hitachi Semiconductor)
Other Datasheets by Hitachi

Full PDF Text Transcription

Click to expand full text
www.DataSheet4U.com www.DataSheet4U.com DataSheet 4 U .com www.DataSheet4U www.DataSheet4U.com 4U.com www.DataSheet4U.com HM5116400 Series HM5117400 Series 4,194,304-word × 4-bit Dynamic RAM ADE-203-648C (Z) Rev. 3.0 Feb. 27, 1997 Description The Hitachi HM5116400 Series, HM5117400 Series are CMOS dynamic RAMs organized 4,194,304-word × 4-bit. They employ the most advanced 0.5 µm CMOS technology for high performance and low power. The HM5116400 Series, HM5117400 Series offer Fast Page Mode as a high speed access mode. They have package variations of standard 300-mil 26-pin plastic SOJ and standard 300-mil 26-pin plastic TSOP.
