HMC-C002 Datasheet, Module, Hittite Microwave

HMC-C002 Features

• Module Noise Figure: 2 dB @ 8 GHz Flat Gain: 13 dB ± 0.5 dB P1dB Output Power: +18 dBm @ 8 GHz 50 Ohm Matched Input/Output Typical Applications The HMC-C002 Wideband LNA is ideal for:

PDF File Details

Part number:

HMC-C002

Manufacturer:

Hittite Microwave

File Size:

624.58kb

Download:

📄 Datasheet

Description:

Wideband lna module. The HMC-C002 is a GaAs MMIC PHEMT Low Noise Distributed Amplifier in a miniature, hermetic module with replaceable SMA connectors whi

HMC-C002 Application

• Applications The HMC-C002 Wideband LNA is ideal for:
• Telecom Infrastructure
• Microwave Radio & VSAT
• Military & Space

TAGS

HMC-C002

Hittite Microwave
