CSLA1DE

The CSLA1DE is Linear Current Sensors designed by Honeywell.

Product Overview

Honeywell

Part number	CSLA1DE, CSLA1CD
Manufacturer	Honeywell
File Size	783.51 KB
Description	Linear Current Sensors
Datasheet	CSLA1CD-Honeywell.pdf
Note	This datasheet PDF includes multiple part numbers: CSLA1DE, CSLA1CD. Please refer to the document for exact specifications by model.
Additional preview pages of the CSLA1DE datasheet.

Honeywell’s CSLW Series miniature, open-loop current sensors incorporate our SS490 Series miniature ratiometric linear Hall-effect sensor (MRL ).

ɀ Linear output ɀ AC or DC current sensing ɀ Through-hole design ɀ Fast response time ɀ Output voltage isolation from input ɀ Minimum energy dissipation ɀ Maximum current limited only by conductor size ɀ Adjustable performance and built-in temperature compensation assures reliable operation ɀ Accurate, low cost sensing ɀ Operating temperature range.
25 to 85°C ɀ Housing: PET polyester ORDER GUIDE.
BOTTOM MOUNT WITH 9SS SENSOR, SOURCE OUTPUT Mtg. Dim. Fig. 1 1 2 1 2 1 2 1a 2 1a 1.
