MMA0204 Datasheet - IRC

MMA0204 (MM Series) Cylindrical General Purpose Surface Mount Power Resistor

CYLINDRICAL GENERAL PURPOSE SURFACE MOUNT POWER RESISTOR METAL GLAZE™ ISO-9001 Registered MM SERIES Up to 2 watts 0.1 ohm to 2.2 megohm range Up to 1000 volts 150°C maximum operating temperature Size Code B F H 1 Metal GlazeTM thick film element fired at 1000°C to solid ceramic substrate High temperature dielectric coating 60/40 Solder over nickel barrier MM SPECIFICATIONS: IRC Type MMA0204 MMB0207 MMC0310 Maximum Power Rating 1/4W @ 70°C 1W @ 70°C 2W @ 25°C 1.33W @ .

MMA0204_IRC.pdf

MMA0204 Datasheet Preview — Preview of MMA0204 PDF

MMA0204 Datasheet Preview Page 2

Datasheet Details

Part number:

MMA0204

Manufacturer:

IRC

File Size:

84.24 KB

Description:

(mm series) cylindrical general purpose surface mount power resistor.
