CPC1706 Datasheet, Relay, IXYS

CPC1706 Features

• Relay
• Handle Load Currents Up to 4ADC
• 2500Vrms Input/Output Isolation
• Power SIP Package
• High Reliability
• Low Drive Power Requirements

PDF File Details

Part number:

CPC1706

Manufacturer:

IXYS

File Size:

133.94kb

Download:

📄 Datasheet

Description:

Dc power sip relay. IXYS Integrated Circuits brings OptoMOS® technology, reliability, and compact size to a new family of high power solid state relays.

CPC1706 Application

• Applications
• Industrial Controls
• Motor Control
• Robotics
• Medical Equipment
    –Patient/Equipment
