2SK683 - N-Channel MOSFET Transistor

2SK683 Description

isc N-Channel MOSFET Transistor .
Drain Current. ID=12A@ TC=25℃. Drain Source Voltage- : VDSS=500V(Min). Fast Switching Speed. 100% avalanche tested. Minim.

2SK683 Applications

* low on
* resistance
* High speed switching
* Low drive current
* No secondary breakdown
* Suitable for switchingregulator, DC
* DC convertor ABSOLUTE MAXIMUM RATINGS(Ta=25℃) SYMBOL ARAMETER VALUE UNIT VDSS Drain-Source Voltage (VGS=0) 500 V VGS Gate-Source Voltag

📥 Download Datasheet

Preview of 2SK683 PDF
datasheet Preview Page 2

Datasheet Details

Part number
2SK683
Manufacturer
Inchange Semiconductor
File Size
236.39 KB
Datasheet
2SK683-InchangeSemiconductor.pdf
Description
N-Channel MOSFET Transistor
