2SK954 N-Channel MOSFET Transistor

2SK954 Description

isc N-Channel MOSFET Transistor 2SK954 .
Drain Current. ID=3A@ TC=25℃. Drain Source Voltage- : VDSS=800V(Min). Fast Switching Speed. Minimum Lot-to-Lot variations for.

2SK954 Applications

* Designed especially for high voltage.
* high speed power switching. ABSOLUTE MAXIMUM RATINGS(Ta=25℃) SYMBOL PARAMETER VALUE UNIT VDSS Drain-Source Voltage (VGS=0) 800 V VGS Gate-Source Voltage ±20 V ID Drain Current-continuous@ TC=25℃ 3 A Ptot Total Dissipation@TC=25℃ 100 W

📥 Download Datasheet

Preview of 2SK954 PDF
datasheet Preview Page 2

Datasheet Details

Part number
2SK954
Manufacturer
Inchange Semiconductor
File Size
202.51 KB
Datasheet
2SK954-InchangeSemiconductor.pdf
Description
N-Channel MOSFET Transistor
