BU4522AF - Silicon NPN Power Transistor

Datasheet Summary

Description

Collector-Emitter Sustaining Voltage: VCEO(SUS)= 800V (Min) High Switching Speed APPLICATIONS

Designed for use in horizontal deflection circuits of color TV receivers and PC monitors.

Inchange Semiconductor

📥 Download Datasheet

Datasheet Details

Part number	BU4522AF
Manufacturer	Inchange Semiconductor
File Size	232.92 KB
Description	Silicon NPN Power Transistor
Datasheet	BU4522AF Datasheet
Additional preview pages of the BU4522AF datasheet.

📁 Similar Datasheet

BU4522AF - Silicon Diffused Power Transistor (NXP)
BU4522AX - Silicon Diffused Power Transistor (NXP)
BU4522AX - NPN Transistor (INCHANGE)
BU4522DF - Silicon Diffused Power Transistor (NXP)
BU4522DX - Silicon Diffused Power Transistor (NXP)
BU4523AF - Silicon Diffused Power Transistor (NXP)
BU4523AW - Silicon Diffused Power Transistor (NXP)
BU4523AX - Silicon Diffused Power Transistor (NXP)
BU4523DF - Silicon Diffused Power Transistor (NXP)
BU4523DW - Silicon Diffused Power Transistor (NXP)

Other Datasheets by Inchange Semiconductor

BU4525AX - Silicon NPN Power Transistor
BU4508AF - Silicon NPN Power Transistor
BU4508DX - Silicon NPN Power Transistor
BU433 - Silicon NPN Power Transistor

Full PDF Text Transcription

Click to expand full text

INCHANGE Semiconductor isc Product Specification www.DataSheet4U.com isc Silicon NPN Power Transistor BU4522AF DESCRIPTION ·Collector-Emitter Sustaining Voltage: VCEO(SUS)= 800V (Min) ·High Switching Speed APPLICATIONS ·Designed for use in horizontal deflection circuits of color TV receivers and PC monitors. ABSOLUTE MAXIMUM RATINGS(Ta=25℃) SYMBOL VCES VCEO VEBO IC ICM IB B PARAMETER Collector- Emitter Voltage(VBE= 0) Collector-Emitter Voltage Emitter-Base Voltage VALUE 1500 800 7.5 10 UNIT V V Collector Current- Continuous Collector Current-Peak Base Current- Continuous Base Current-Peak w ww s c s .i V A 25 6 9 45 150 -55~150 A A A W ℃ ℃ n c .

Published: Apr 15, 2010 |
