D2110 - 2SD2110

D2110 Description

INCHANGE Semiconductor www.DataSheet4U.com isc Silicon NPN Darlington Power Transistor isc Product Specification 2SD2110 .
Collector-Emitter Breakdown Voltage- : V(BR)CEO= 80V(Min). Collector-Emitter Saturation Voltage- : VCE(sat)= 1. High DC C.

D2110 Applications

* Designed for low frequency power amplifier applications ABSOLUTE MAXIMUM RATINGS(Ta=25℃) i. cnSYMBOL PARAMETER VALUE UNIT . iscsemVCBO Collector-Base Voltage 80 V wwwVCEO Collector-Emitter Voltage 80 V VEBO Emitter-Base Voltage 7V IC Collector Current-Continuous 4A ICM Collector

📥 Download Datasheet

Preview of D2110 PDF
datasheet Preview Page 2
