ICE3B1565J (ICE3Bxx65J) Off-Line SMPS Current Mode Controller

The CoolSET™-F3(Jitter version) meets the requirements for Off-Line Battery Adapters and low cost SMPS for the lower power range. By use of a BiCMOS technology a wide VCC range up to 26V is provided. This covers the changes in the auxiliary supply voltage if a CV/CC regulation is implemented on the .

Version 2.3, 8 May 2006 CoolSET™-F3 (Jitter Version) ICE3 B03 6 5 J ICE3 B05 6 5 J ICE3 B15 6 5 J Off-Line SMPS Current Mode Controller with integrated 650V Startup Cell/Depletion CoolMOS™ Power Management & Supply N e v e r s t o p t h i n k i n g . CoolSET™-F3 ICE3Bxx65J Revision History: Page 6, 8, 12, 13 11, 12 2006-05-08 Datasheet Previous Version: 2.2 ( ICE3B0365J/ICE3B0565J ), 2.0 ( ICE3B1565J ) Subjects (major changes since last revision) Group ICE3B0365J, ICE3B0565J and ICE3B15.

ICE3B1565J Features

* 650V Avalanche Rugged CoolMOS™ with built in switchable Startup Cell Active Burst Mode for lowest Standby Power @ light load controlled by Feedback Si
