09A22210

Analog AMR/GMR Angle Sensors

Infineon

09A22210 Datasheet (1.13 MB)

09A22210 Datasheet Preview — Preview of 09A22210 PDF

Datasheet Details

Part number:

09A22210

Manufacturer:

Infineon ↗

File Size:

1.13 MB

Description:

Analog amr/gmr angle sensors.

09A22210 Features

* Single and dual die sensor with AMR or GMR technology

* Separate supply pins for top and bottom sensor

* Low current consumption and quick start up

* 180°(AMR) and 360°(GMR) contactless angle measurement

* Output amplitude optimized for circuits with 3.3 V o

09A22210 General Description

The TLE5x0916(D) are angle sensor with analog outputs. They detect the orientation of a magnetic field by measuring sine and cosine angle components with Magneto Resistive (MR) elements. The sensors provide analog sine and cosine output voltages that describe the magnetic angle in a range of 0 to 18.
