6EDL04I065PR, 6EDL04I065NR - three-phase gate driver

Infineon

6EDL04I065PR Datasheet Preview — This datasheet PDF includes multiple part numbers: 6EDL04I065PR, 6EDL04I065NR. Please refer to the document for exact specifications by model.

Datasheet Details

Part number	6EDL04I065PR, 6EDL04I065NR
Manufacturer	Infineon ↗
File Size	953.79 KB
Description	three-phase gate driver
Datasheet	6EDL04I065NR-Infineon.pdf
Note	This datasheet PDF includes multiple part numbers: 6EDL04I065PR, 6EDL04I065NR. Please refer to the document for exact specifications by model.

6EDL04I065PR Product details

Description

The device 6ED family 3rd generation is a full bridge driver to control power devices like MOS-transistors or IGBTs in 3-phase systems with a maximum blocking voltage of +650 V.

Features

Infineon thin-film-SOI-technology.
Maximum blocking voltage +650 V.
Output source/sink current +0.165 A/-0.375 A.
Integrated ultra-fast, low RDS(ON) Bootstrap Diode.
Insensitivity of the bridge output to negative transient voltages up to -50 V given by SOItechnology.
Separate control circuits for all six drivers.
Detection of over current and under voltage supply.
Externally programmable delay for fault clear after over cur.
