BGT24ATR22

24GHz radar sensor

Infineon

BGT24ATR22 Features

* 24 GHz radar transceiver MMIC

* 2 TX channels

* 2 RX channels

* Fully integrated low-phase-noise VCO

* Low noise figure NFSSB: 13 dB @1 kHz

* Automatic frequency control

* Integrated analog base band amplifiers

* Automatic DC-offset c

BGT24ATR22 General Description

BGT24ATR22 is a Silicon Germanium Monolithic Microwave Integrated Circuit for 24 GHz radar applications. It provides building blocks for analog signal generation and reception, operating in the frequency range from 24.0 GHz up to 24.25 GHz with 2 transmit channels and 2 receive channels. The analog .
