N channel vertical power FET with charge pump, ground referenced CMOS compatible input and diagnostic feedback, monolithically integrated in Smart SIPMOS technology.Providing embedded protective functions.Voltage source V
Logic
Overvoltage protection
Current limit 1
Gate 1 protection
+ V bb
4
Voltage sensor
Level shifter Rectifier 1 Charge pump 1 Charge pump 2
Limit for unclamped ind.loads 1 Open load Short to Vbb detection 1 Current limit 2 Gate 2 prot
Features
- Product Summary Overvoltage protection Operating voltage Operating temperature
Vbb(AZ) Vbb(on) Ta
43 V 5.0 34 V -30…+85 °C
both
channels: On-state resistance RON Load current (ISO) IL(ISO) Current limitation IL(SCr)
each parallel 100 50 mΩ 4.4 8.5 A 8 8 A
PG-TO220AB/7.
