K50EEH5 - High-speed5 IGBT

Datasheet Summary

Features

C High speed H5 technology offering.
Best-in-Class efficiency in hard switching and resonant topologies.
Plug and play replacement of previous generation IGBTs.
650V breakdown voltage.
Low gate charge QG.
IGBT copacked with full-rated RAPID 1 fast and soft antiparallel diode.
Maximum junction temperature 175°C.
Qualified according to JEDEC for target.

Infineon

📥 Download Datasheet

Datasheet Details

Part number	K50EEH5
Manufacturer	Infineon
File Size	1.87 MB
Description	High-speed5 IGBT
Datasheet	K50EEH5 Datasheet
