PXE1110CDM, PXE1610CDN VR13 and VR12.5 Multi-rail / Multiphase Digital Controllers

Infineon

Description

VR13 and VR12.5 Multi-rail / Multiphase Digital Controllers Enterprise / Memory Lines Enterprise Line Applications Enterprise Line .
Vcore power regulation for Intel® VR13 rev1.

📥 Download Datasheet

PXE1110CDM Datasheet Preview — This datasheet PDF includes multiple part numbers: PXE1110CDM, PXE1610CDN. Please refer to the document for exact specifications by model.

Datasheet Specifications

Part number: PXE1110CDM, PXE1610CDN
Manufacturer: Infineon ↗
File Size: 1.33 MB
Datasheet: PXE1610CDN-Infineon.pdf
Description: VR13 and VR12.5 Multi-rail / Multiphase Digital Controllers
Note: This datasheet PDF includes multiple part numbers: PXE1110CDM, PXE1610CDN.
Please refer to the document for exact specifications by model.

Features

* Compliant to Intel® VR13 and VR12.5 DC-DC converter specifications
* Compliant to Intel® SVID protocol rev1.7
* Output voltage regulation range  0.5V to 2.5V (10mV/step)  0.25V to 1.52V (5mV/step)
* Programmable to support one, two, or three fully digitally controlled voltage rai
