IP5326 - 2.4A Charge/Discharge Power Bank SOC

Datasheet Summary

Description

Integrated LED controller supports 4、2、1 LEDs as the SOC indicator The battery level curve can be selected by PIN, and the display light is more uniform Fully featured IC Built-in light drive Integrated cellphone plug-in and plug-out detector Integrated Type-C DRP protocol, support single port inpu

Features

  • es Synchronous switch charge and discharge 2.4A Synchronous switching charger and 2.4A boost converter Boost converter efficiency up to 96% Switching charger efficiency up to 94% Integrated power-path management, charging batteries and charging cellphones at the same time Charger Adaptive charging current control, adaptive adapter output capability Support 4.20V/4.30V/4.35V/4.40V batteries State of charge (SOC) indicator.
  • In-depth customization.
  • I2C interface for flexible and low cost.

📥 Download Datasheet

Datasheet preview – IP5326

Datasheet Details

Part number IP5326
Manufacturer Injoinic
File Size 1.01 MB
Description 2.4A Charge/Discharge Power Bank SOC
Datasheet download datasheet IP5326 Datasheet
Additional preview pages of the IP5326 datasheet.

📁 Similar Datasheet

  • IP5305 - high integration mobile power SOC (ChipSourceTek)
  • IP5306CX8 - Integrated Differential Microphone Filter (NXP)
  • IP5311CX5 - Dual-channel Integrated Passive Filter Network (NXP)
  • IP5020 - Internet Access Server (ETC)
  • IP5560 - POWER SUPPLY CONTROLLER (Seme LAB)
  • IP5560C - POWER SUPPLY CONTROLLER (Seme LAB)
  • IP5561C - POWER SUPPLY CONTROLLER (Seme LAB)
  • IP5661 - SWITCHED.MODE POWER SUPPLY CONTROL CIRCUIT (Seme LAB)
  • IP5661C - SWITCHED.MODE POWER SUPPLY CONTROL CIRCUIT (Seme LAB)
  • IP568x - 56K V.90 Modem Shngle Chip (IC ACE)
Other Datasheets by Injoinic
  • IP5320 - 3A Charge/Discharge Power Bank SOC
  • IP5322 - Fully-Integrated Fast Charge Power Bank SOC
  • IP5328 - Mobile Power SOC
  • IP5328P - Fully-Integrated Bi-directional PD3.0 and Fast Charge Power-Bank SOC
  • IP5303 - 1.2A Charging 1.0A Discharge Highly Integrated Mobile Power SOC
  • IP5303T - 1.2A charging 1.0A discharging Highly integrated mobile power supply SOC
  • IP5305 - Fully-integrated power bank System-On-Chip
  • IP5305T - Fully-integrated power bank System-On-Chip

Full PDF Text Transcription

Click to expand full text
IP5326 2.4A Charge/Discharge Power Bank SOC Integrated With TYPE_C Protocol 1.                         Features Synchronous switch charge and discharge 2.4A Synchronous switching charger and 2.4A boost converter Boost converter efficiency up to 96% Switching charger efficiency up to 94% Integrated power-path management, charging batteries and charging cellphones at the same time Charger Adaptive charging current control, adaptive adapter output capability Support 4.20V/4.30V/4.35V/4.40V batteries State of charge (SOC) indicator  In-depth customization  I2C interface for flexible and low cost customized solution . Custom Version :IP5326_I2C 2. Applications p  Power bank r  Mobile Phones, Smart Phones, Handheld Devices, Portable Media Player, Tablet Co 3.
