IP6805S

Highly integrated 5W wireless charging transmitter controller

IP6805S Features

* .

* Compliant with WPC specificatiosn transmitter design

* Support 5W applications p

* Support FOD (Foreign Object Detection) function o

* High sensitivity

* Support dynamic FOD r

* Low quiescent dissipation and high efficiency

* 4mA quiescent current C

* Low power au

IP6805S General Description

IP6805S is a wireless power transmitter controller SoC that integrates all required functions for WPC Qi specifications compliant wireless power transmitter design. Support A11 coil, support 5W charging. It used Analog Ping to detect a RX wireless device for charging with low standby power. Communic.

IP6805S Datasheet (1.40 MB)

Preview of IP6805S PDF
