IRKT26 Datasheet, Thyristor, International Rectifier

IRKT26 Features

• Thyristor High Voltage Industrial Standard Package Thick Al metal die and double stick bonding Thick copper baseplate UL E78996 approved 3500VRMS isolating voltage ADD-A-pakTM GEN V Power Module

PDF File Details

Part number:

IRKT26

Manufacturer:

International Rectifier

File Size:

146.94kb

Download:

📄 Datasheet

Description:

Thyristor/ diode and thyristor/ thyristor. The Generation V of Add-A-pak module combine the excellent thermal performance obtained by the usage of Direct Bonded Copper substrat

IRKT26 Application

• Applications such as high voltage regulated power supplies, lighting circuits, temperature and motor speed control circuits, UPS and battery charger

TAGS

IRKT26

International Rectifier
