OMC506

Closed Loop Speed Controller For 3-Phase Brushless DC Motor MP-3T Package

OMC506 Datasheet (75.31 KB)

Preview of OMC506 PDF

Datasheet Details

Part number:

OMC506

Manufacturer:

International Rectifier

File Size:

75.31 KB

Description:

Closed loop speed controller for 3-phase brushless dc motor mp-3t package.

OMC506 Features

* n 10A Average Phase Output Current n Over Temperature Protection n Compensation Circuitry Adjustable to Motor Parameters n Speed Controlled by 0 to 5V Linear Input Signal n Forward or Reverse Direction n Isolated, Low Profile Package Absolute Maximum Ratings Symbol VM VM pk IO IOP IOSC VREF IREF

OMC506 General Description

The OMC506 is an integrated, high density, three phase Brushless DC (BLDC) motor, speed controller housed in a MP-3Tpackage. The OMC506 contains the power, driver and control electronics to adjust timing functions and speed control loop parameters to optimize the controller for each application. Th.
