High surge current capability
S5A THRU S5M
5A, 50V - 1000V Surface Mount Rectifiers
A
B
DIM A B C D E F G H
G C
D E
F Cathode Band H
DO-214AB (SMC)
INCHES
MM
MIN MAX MIN MAX
0.081
0.103
2.06
2.62
0.114
0.126
2.90
3.20
--- 0.008 ---
0.20
0.030
0.060
0.76
1.52
0.305
0.320
7.75
8.13
0.260
0.280
6.60
7.11
0.006
0.012
0.152
0.305.
