JCS50N20ABT Datasheet, Mosfet, JILIN SINO-MICROELECTRONICS

JCS50N20ABT Features

• Mosfet
• Low gate charge
• Low Crss
• Fast switching
• 100% avalanche tested
• Improved dv/dt capability
• RoHS product ORDER MESSAGE Order codes

PDF File Details

Part number:

JCS50N20ABT

Manufacturer:

JILIN SINO-MICROELECTRONICS

File Size:

1.09MB

Download:

📄 Datasheet

Description:

N-channel mosfet.

JCS50N20ABT Application

• Applications
• High frequency switch mode power supplies
• Electronic lamp ballasts based on half bridge
• UPS
• <
