1N5921 - 1.5W SILICON PLANAR ZENER DIODES

1N5921 Description

R SEMICONDUCTOR 1N5921 THRU 1N5956 1.5W SILICON PLANAR ZENER DIODES .

1N5921 Features

* Low leakage, low zener impedance at low current Maximum power dissipation of 1.5W is ideally suited for stabilized power supply, etc. High temperature soldering guaranteed:260°C/10 seconds at terminals MECHANICAL DATA DO-41 JF 0.110(2.8) 0.080(2.0) DIA 1.0(25.4) MIN 0.205(5.20) 0.161(4.10) Case:

📥 Download Datasheet

Preview of 1N5921 PDF
datasheet Preview Page 2

Datasheet Details

Part number
1N5921
Manufacturer
JINAN JINGHENG
File Size
62.62 KB
Datasheet
1N5921-JINANJINGHENG.pdf
Description
1.5W SILICON PLANAR ZENER DIODES
