SMA4756 1W SILICON PLANAR ZENER DIODES

SMA4756 Features

* SMA(DO-214AC) Low leakage, low zener impedance at low current Maximum power dissipation of 1W is ideally suited for stabilized power supply, etc. High temperature soldering guaranteed:260°C/10 seconds at terminals 0.065(1.65) 0.049(1.25) 0.181(4.60) 0.157(3.99) 0.114(2.9) 0.100(2.54) MECHANICA

SMA4728-JinanJingHengElectronics.pdf

SMA4756 Datasheet Preview — This datasheet PDF includes multiple part numbers: SMA4756, SMA4728. Please refer to the document for exact specifications by model.

Datasheet Details

Part number:

SMA4756, SMA4728

Manufacturer:

Jinan Jing Heng Electronics

File Size:

66.17 KB

Description:

1w silicon planar zener diodes.

Note:

This datasheet PDF includes multiple part numbers: SMA4756, SMA4728.
Please refer to the document for exact specifications by model.
