S2JBF Datasheet - Jingdao Microelectronics

Surface Mount General Purpose Silicon Rectifiers

S2JBF Features

* For surface mounted applications

* Low profile package

* Glass Passivated Chip Junction

* Easy to pick and place

* Lead free in comply with EU RoHS 2011/65/EU directives MECHANICAL DATA

* Case: SMBF

* Terminals: Solderable per MIL-STD-750, Me

S2JBF General Description

1 Cathode 2 Anode 12 Top View Marking Code： S2AB-S2MB Simplified outline SMBF and symbol Maximum Ratings and Electrical characteristics Ratings at 25 °C ambient temperature unless otherwise specified. Single phase half-wave 60 Hz, resistive or inductive load, for capacitive load current derate by 2.

S2JBF Datasheet (65.81 KB)

Preview of S2JBF PDF

Datasheet Details

Part number:

S2JBF

Manufacturer:

Jingdao Microelectronics

File Size:

65.81 KB

Description:

Surface mount general purpose silicon rectifiers.
