KSM-951TM4Y Datasheet (KODENSHI KOREA CORP)

KSM-951TM4Y, Optic receiver module

1) Transmitter(IRED) drive current : IFP = 300mAP-P ~ 600mAP-P 2) R-C Decoupling Filter with Lower Cut-off Frequency : R=100 *Ù , C=47 *Þ : 10k *Ù over ¢¡ fc = 1/2 *ð RC = 33.9Hz 3) External pull-up resistor(optional) Vcc C Rp micom GND 2/2

KSM-951TM4Y Features

* ¤ýOne mold small size package ¤ýWide supply-voltage range : 2.7V to 5.5V ¤ýShielded against electrical field disturbance ¤ýHigh immunity against ambient light disturbances (Logic Controller Adaptation) ¤ýAvailable for carrier frequencies between 32.7KHz to 56.9KHz ¤ýTTL and CMOS compatible Applicat
