S37703, S37701 Datasheet - KODENSHI KOREA

S37703, S37701, 8CH Darlington TR Sink Driver

Semiconductor http:// www.auk.co.kr SOP-20 S3770x/P 8CH Darlington TR Sink Driver .
The S3770x Series are high-voltage, high-current Darlington transistor arrays.

datasheet Preview Page 1 from Datasheet4u.com

S37701-KODENSHIKOREA.pdf

S37703 Datasheet Preview — This datasheet PDF includes multiple part numbers: S37703, S37701. Please refer to the document for exact specifications by model.

Datasheet Details

Part number:

S37703, S37701

Manufacturer:

KODENSHI KOREA

File Size:

401.34 KB

Description:

8CH Darlington TR Sink Driver

Note:

This datasheet PDF includes multiple part numbers: S37703, S37701.
Please refer to the document for exact specifications by model.

Features

* ◈ Output Current (single output) 500mA(Max. ) ◈ High sustaining voltage output ◈Output clamp diode ◈ Inputs compatible with various types of logic ◈ Package : SOP-20, DIP-18 ▲ Marking Detail

Applications

* include relay drivers, hammer drivers, lamp drivers, display drivers (LED and gas discharge), line drivers, and logic buffers. DIP-18 ORDERING INFORMATION Product S3770x S3770xP Marking S3770x S3770x Package SOP-20 DIP-18 Application ◈ Relay Controller ◈ Lamp and Display LED Driver ◈ Motor Dri
