57BYGH803 Datasheet - KySan

57BYGH803 HB Stepper Motors

Fax Orders to 650-960-3875 HB Stepper Motors Step Angle 1.8°±5% Insulation Resistant 500V DC 100MO Min Insulation Strength 50Hz 1Minute 500V Min Ambient Temperature -20ºC~+50ºC Temperature Rise 80ºC Max Shaft Radial Play 0.02mm Max Shaft End Play 0.1-0.3mm Stepper Motor 35BYG, 39BYG Series HB Stepper Motors Kysan# 1121001 1121002 1121003 1121004 1121005 1121006 1121007 1121008 1121009 1121010 1121011 1121012 1121013 1121014 1121002 1121004 1121006 www.DataSheet4U.com 1121007 1121008 1122001 .

57BYGH803 Datasheet (1.41 MB)

Preview of 57BYGH803 PDF
57BYGH803 Datasheet Preview Page 2 57BYGH803 Datasheet Preview Page 3

Datasheet Details

Part number:

57BYGH803

Manufacturer:

KySan

File Size:

1.41 MB

Description:

Hb stepper motors.
