Description

Current Transducer HOB-P series IP N = 50 … 130 A Ref: HOB 50-P, HOB 75-P, HOB 100-P, HOB 130-P For the electronic measurement of current: DC, AC, .

📥 Download Datasheet

HOB50-P Datasheet Preview — Preview of HOB50-P PDF

Datasheet Specifications

Part number: HOB50-P
Manufacturer: LEM
File Size: 891.82 KB
Datasheet: HOB50-P-LEM.pdf
Description: Current Transducer

Features

* Open loop multi-range current transducer
* Voltage output
* Single power supply +5 V
* Galvanic separation between primary and secondary circuit
* Low power consumption
* Compact design for THT PCB mounting
* Factory calibrated. Advantages
* Low offset temperature d

Applications

* AC variable speed and servo motor drives
* Static converters for DC motor drives
* Battery supplied applications
* Uninterruptible Power Supplies (UPS)
* Switched Mode Power Supplies (SMPS)
* Combiner box
* Solar inverter on DC side of the inverter (MPPT)
* Plasma c
