LC420WUN-SAB1 - LCD Module

LC420WUN-SAB1 Datasheet Preview — Preview of LC420WUN-SAB1 PDF

Datasheet Details

Part number	LC420WUN-SAB1
Manufacturer	LG
File Size	825.37 KB
Description	LCD Module
Datasheet	LC420WUN-SAB1_LG.pdf

LC420WUN-SAB1 Product details

Description

ABSOLUTE MAXIMUM RATINGS ELECTRICAL SPECIFICATIONS ELECTRICAL CHARACTERISTICS INTERFACE CONNECTIONS SIGNAL TIMING SPECIFICATIONS SIGNAL TIMING WAVEFORMS COLOR DATA REFERENCE POWER SEQUENCE OPTICAL SPECIFICATIONS MECHANICAL CHARACTERISTICS RELIABILITY INTERNATIONAL STANDARDS SAFETY EMC PACKING DESIGNATION OF LOT MARK PACKING FORM PRECAUTIONS MOUNTING PRECAUTIONS OPERATING PRECAUTIONS ELECTROSTATIC DISCHARGE CONTROL PRECAUTIONS FOR STRONG LIGHT EXPOSURE STORAGE HANDLING PRECAUTIONS FOR PROTECTION

Features

Active Screen Size Outline Dimension Pixel Pitch Pixel Format Color Depth Luminance, White Viewing Angle (CR>10) Power Consumption Weight Display Mode Surface Treatment 42.02 inches(1067.31mm) diagonal 983.0(H) x 576.0 (V) x 51.0 mm(D) (Typ. ) 0.4845 mm x 0.4845 mm 1920 horiz. by 1080 vert. Pixels, RGB stripe arrangement 10bit (D) , 1.06Billon colors 500 cd/m2 (Center 1point ,Typ. ) Viewing angle free ( R/L 178 (Typ. ), U/D 178 (Typ. )) Total 167.5 W (Typ. ) (Logic = 6.7 W, Inverter = 160.8 W [VBR-A=.
