LSJ74D, LSJ74 P-CHANNEL JFET

LINEAR SYSTEMS

Description

LSJ74, SST74 ULTRA LOW NOISE SINGLE P-CHANNEL JFET .

📥 Download Datasheet

LSJ74D Datasheet Preview — This datasheet PDF includes multiple part numbers: LSJ74D, LSJ74. Please refer to the document for exact specifications by model.

Datasheet Specifications

Part number: LSJ74D, LSJ74
Manufacturer: LINEAR SYSTEMS
File Size: 239.52 KB
Datasheet: LSJ74-LINEARSYSTEMS.pdf
Description: P-CHANNEL JFET
Note: This datasheet PDF includes multiple part numbers: LSJ74D, LSJ74.
Please refer to the document for exact specifications by model.

Features

* ULTRA LOW NOISE (f = 1kHz) en = 0.9nV/√Hz HIGH GAIN Gfs = 22mS (typ) HIGH INPUT IMPEDANCE IG = 1.0nA LOW CAPACITANCE CRSS = 32pF IMPROVED SECOND SOURCE REPLACEMENT FOR 2SJ74 ABSOLUTE MAXIMUM RATINGS1 @ 25 °C (unless otherwise stated) Maximum Temperatures Storage Temperature Junction Opera
