LT1021 Datasheet, Reference, Linear Technology

LT1021 Features

• Reference
• Ultralow Drift: 5ppm/°C Max Slope
• Very Low Noise: <1ppm P-P (0.1Hz to 10Hz)
• 100% Noise Tested
• Pin Compatible with Most Bandgap Reference Applicat

PDF File Details

Part number:

LT1021

Manufacturer:

Linear Technology

File Size:

209.55kb

Download:

📄 Datasheet

Description:

Precision reference.

LT1021 Application

• Applications Including Ref 01, Ref 02, LM368, MC1400 and MC1404 with Greatly Improved Stability, Noise and Drift
• Trimmed Output Voltage <
