LTC1060
Universal Dual Filter Building Block
FEATURES
■ Guaranteed Filter Specification for ±2.37V and ±5V Supply
■ Operates Up to 30kHz ■ Low Power and 88dB Dynamic Range at ±2.5V Supply ■ Center Frequency Q Product Up to 1.6MHz ■ Guaranteed Offset Voltages ■ Guaranteed Clock-to-Center Frequency Accuracy Over
Temperature: 0.3% for LTC1060A 0.8% for LTC1060
■ Guaranteed Q Accuracy Over Temperature ■ Low Temperature Coefficient of Q and Center
Frequency ■ Low Crosstalk, 70dB ■ Clock Inputs TTL and CMOS Compatible
U APPLICATIO S
■ Single 5V Supply Medium Frequency Filters ■ Very High Q and High Dynamic Range Bandpass,
Notch Filters ■ Tracking Filters ■ Telecom Filters
DESCRIPTIO
The LTC®1060 consists of two high performance, switched capacitor filters.
