LTC2204

65Msps/40Msps ADC

Image Manufacturer B2B MPN Description Distributor Stock Quantity Price Buy Now
Distributor Analog Devices Inc LTC2204IUK-PBF IC ADC 16BIT PIPELINED 48QFN DigiKey 79 10 units
$67.58

LTC2204 Datasheet (1.34 MB)

Preview of LTC2204 PDF Datasheet

Datasheet Details

Part number:

LTC2204

Manufacturer:

Linear Technology

File Size:

1.34 MB

Description:

65msps/40msps adc.

LTC2204 Features

* n Sample Rate: 65Msps/40Msps n 79dB SNR and 100dB SFDR (2.25VP-P Range) n SFDR >92dB at 140MHz (1.5VP-P Input Range) n PGA Front End (2.25VP-P or 1.5VP-P Input Range) n 700MHz Full Power Bandwidth S/H n Optional Internal Dither n Optional Data Output Randomizer n Single 3.3V Supply n Power Dissipati

LTC2204 General Description

The LTC®2205/LTC2204 are sampling 16-bit A/D converters designed for digitizing high frequency, wide dynamic range signals up to input frequencies of 700MHz. The input range of the ADC can be optimized with the PGA front end. The LTC2205/LTC2204 are perfect for demanding communications applications,.
