LTC2206-14

14-Bit ADCs

LTC2206-14 Features

* nn Sample Rate: 105Msps/80Msps nn 77.3dBFS Noise Floor nn 98dB SFDR nn SFDR >82dB at 250MHz (1.5VP-P Input Range) nn PGA Front End (2.25VP-P or 1.5VP-P Input Range) nn 700MHz Full Power Bandwidth S/H nn Optional Internal Dither nn Optional Data Output Randomizer nn Single 3.3V Supply nn Power Dissip

LTC2206-14 General Description

The LTC®2207-14/LTC2206-14 are 105Msps/80Msps, sampling 14-bit A/D converters designed for digitizing high frequency, wide dynamic range signals up to input frequencies of 700MHz. The input range of the ADC can be optimized with the PGA front end. The LTC2207-14/LTC2206-14 are perfect for demanding .

LTC2206-14 Datasheet (1.75 MB)

Preview of LTC2206-14 PDF

Datasheet Details

Part number:

LTC2206-14

Manufacturer:

Linear Technology

File Size:

1.75 MB

Description:

14-bit adcs.
