LTC2281 Datasheet, Adc, Linear Technology

LTC2281 Features

• Adc n Integrated Dual 10-Bit ADCs n Sample Rate: 125Msps n Single 3V Supply (2.85V to 3.4V) n Low Power: 790mW n 61.6dB SNR, 88dB SFDR n 110dB Channel Isolation at 100MHz n Flexible Input:

PDF File Details

Part number:

LTC2281

Manufacturer:

Linear Technology

File Size:

488.28kb

Download:

📄 Datasheet

Description:

125msps low power 3v adc. The LTC®2281 is a 10-bit 125Msps, low power dual 3V A/D converter designed for digitizing high frequency, wide dynamic range signals.

LTC2281 Application

• Applications n Wireless and Wired Broadband Communication n Imaging Systems n Spectral Analysis n Portable Instrumentation LTC2281 Dual 10-Bit, 125
