1SMB28CAT3G Datasheet - Littelfuse

1SMB28CAT3G TVS Diodes

The 1SMB10CAT3Gv series is designed to protect voltage sensitive components from high voltage, high energy transients. They have excellent clamping capability, high surge capability, low zener impedance and fast response time. The 1SMB10CAT3G series is supplied in the Littelfuse exclusive, cost-effe.

1SMB28CAT3G Features

* Maximum Ratings and Thermal Characteristics Parameter Symbol Value Unit Peak Power Dissipation (Note 1) @ TL = 25°C, Pulse Width = 1 ms PPK 600 W

* Working Peak Reverse Voltage Range

* 10 V to 75 V

* Standard Zener Breakdown Voltage Range

* 11.7 V to 91.7 V

1SMB28CAT3G Datasheet (1.19 MB)

Preview of 1SMB28CAT3G PDF

Datasheet Details

Part number:

1SMB28CAT3G

Manufacturer:

Littelfuse ↗

File Size:

1.19 MB

Description:

Tvs diodes.
