SA16AG - Zener Transient Voltage Suppressors

Product Overview

Littelfuse

📥 Download Datasheet

SA16AG Zener Transient Voltage Suppressors by Littelfuse - Datasheet Preview — Datasheet preview – SA16AG

Datasheet Details

Part number	SA16AG
Manufacturer	Littelfuse
File Size	316.39 KB
Description	Zener Transient Voltage Suppressors
Datasheet	SA16AG Datasheet
Note	This datasheet PDF includes multiple part numbers: SA16AG, SA100AG. Please refer to the document for exact specifications by model.
Additional preview pages of the SA16AG datasheet.

Product details

Features

Working Peak Reverse Voltage Range.
5.0 to 170 V.
Peak Power.
500 Watts @ 1.0 ms.
ESD Rating of Class 3 (>16 kV) per Human Body Model.
Maximum Clamp Voltage @ Peak Pulse Current.
Low Leakage < 1 mA above 8.5 V.
UL 497B for Isolated Loop Circuit Protection.
Maximum Temperature Coefficient Specified.
Response Time is typica.
