Description
The SAC Series is designed specifically to protect sensitive electronic equipment from voltage transients induced by lightning and other transient voltage events.
Features
- Agency Approvals
AGENCY
AGENCY FILE NUMBER E230531
Maximum Ratings and Thermal Characteristics (TA=25OC unless otherwise noted)
Parameter
Symbol
Peak Pulse Power Dissipation by 10/1000μs Test Waveform (Fig.1) (Note 1)
PPPM
Steady State Power Dissipation on Infinite Heat Sink at TL=75ºC ) Operating Junction and Storage Temperature Range
PD TJ, TSTG
Typical Thermal Resistance Junction to Lead
RθJL
Typical Thermal Resistance Junction to Ambient
RθJA
Value 500
3.0 -65 to 175
20 75
Uni.
SAC26 Datasheet
