F0509S-1WR3

DC/DC Converter

F0509S-1WR3 Features

* Continuous short-circuit protection

* No-load input current as low as 5mA

* Operating ambient temperature range: -40℃ to +105℃ CB Patent Protection RoHS

* High efficiency up to 85%

* I/O isolation test voltage: 3K VDC

* Industry standard pin-out

* SIP package

* IE

F0509S-1WR3 General Description

of reflected ripple current test method. Unit mA VDC Output Specifications Item Voltage Accuracy Linear Regulation Load Regulation Operating Conditions Input voltage change: ±1% 10%-100% load 3.3 VDC output Other output 3.3VDC output 5VDC output 9VDC output Min. Typ. Max. Unit See output reg.
