PWB2405CS-2W, PWB2403CS-1W6 DC/DC CONVERTER

PWB2405CS-2W Description

PWA_CS-2W & PWB_CS-2W Series 2W, ULTRAWIDE INPUT, ISOLATED & REGULATED DUAL/SINGLE OUTPUT, DC/DC CONVERTER multi-country patent protection .

PWB2405CS-2W Features

* High Efficiency up to 82% I/0 Isolation 1500VDC 4:1 wide input range Short circuit protection(automatic recovery) Operating Temperature: -40°C to +85°C Remote ON/OFF control Internal SMD construction Low Ripple and Noise UL94-V0 package RoHS Compliance RoHS PRODUCT PROGRAM Input Part Number PWA240

PWB2405CS-2W Applications

* The PWA_CS-2W & PWB_CS-2W Series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board. These products apply to: 1) Where the voltage of the input power supply is wide r

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: PWB2405CS-2W, PWB2403CS-1W6. Please refer to the document for exact specifications by model.
datasheet Preview Page 2

Datasheet Details

Part number
PWB2405CS-2W, PWB2403CS-1W6
Manufacturer
MORNSUN
File Size
144.54 KB
Datasheet
PWB2403CS-1W6_MORNSUN.pdf
Description
DC/DC CONVERTER
Note
This datasheet PDF includes multiple part numbers: PWB2405CS-2W, PWB2403CS-1W6.
Please refer to the document for exact specifications by model.
